| Model | PW-ST01 |
| With two sets of rolling rollers, 4 sets of test pieces can be produced at the same time. | |
| Rolling weight | 2kg, surface coating rubber hardness 80°±5°, after grinding. |
| Rolling speed | 0~1000mm/min (can be arbitrarily set in touch) |
| Rolling stroke | One or two rounds can be set arbitrarily, and one or two pieces can be rolled; |
| Testing frequency | Arbitrary setting; |
| There is no need to remove the roller to place the test piece, which is convenient and safe to operate; | |
| Rolling wheel width | 45mm; |
| The distance between the two rolling wheels | 70MM; |
| Valid itinerary | About 460MM; |
| When the rolling wheel is reset to the starting point, it hangs naturally to prevent the surface of the wheel from being compressed and deformed; Driven by a servo motor system, the speed and displacement are accurate; |
|
