Test chamber made by PVC board, durable temperature up to 60°C;
Closures made by PVC Impact-resistant board;
Hidden supplementary reagent bottle with water level display, easy to clean and unbreakable;
Saturated air barrel made by SUS#304 material, high pressure-resistant, quality insulation ;
Plane indexing rack, angle adjustable.
Salt spray testing: test chamber 35°C±1°C, saturated air barrel 47°C±1°C
Corrosion test: test chamber 50°C±1°C, saturated air barrel 63°C±1°C
Two-stage adjustment air supply system
Rough adjustment: 2-2.5kg/cm² with oil water filtrate function
Precision adjustment: 1kg/cm² 1/4PT pressure
Take suck salt then flog, uniform atomization, none blocking crystallization, ensure continuous testing.
Adopted special glass nozzle, spray volume & angle can be adjustable
Adjustable spray volume: 1 - 2 ml 80cm²/hr(16 hours average amount)
Directly heating method, speed temperature rising, OFF/OFF auto switch, titanium heating tube.
Test chamber temperature range 0 - 99.9°C, LCD display with P.I.D, control error ± 0.3°C
Saturated air barrel temperature range 0 - 99.9°C, LCD display with P.I.D, control error ± 0.3°C
Heating tank liquid expansion safety temperature range 0-120°C
Saturated air barrel liquid expansion safety temperature control 0-120°C
Digital timer from 0.1s-9990hr
Automatic water adds supplementary system, will be adding when in low water level automatically.
| Model |
PW-CS270 |
| Temperature range |
RT+ 5°C ~ 55°C |
| Temperature uniformity |
2°C |
| Temperature fluctuation |
±0.5 |
| Salt spray sedimentation rate |
1~2ml/80cm²•h |
| Inner size (L×W×H) |
90x60x50cm |
| External size(cm)(L×W×H) |
141x88x128cm |
