Use
Battery washing test machine, the frame body is equipped with a test box, the lower part of the test box is equipped with a washing box, the test box is equipped with a rotating paddle, the inner side of the test box is equipped with a drying device, and the input end of the rotating paddle is connected to a driving motor , The washing box is a box with a liftable structure. The rising of the washing box and the upper edge of the test box form a sealed cavity. The frame is equipped with a control panel and a water tank. The washing box is connected to the water tank through a pipe. The structure design is scientific , It is solved that the battery washing is completely carried out manually step by step, which greatly shortens the test time, improves the test accuracy, and saves time and effort.
Features
1. Built-in SUS316# stainless steel water tank, which can be used for the ratio of alkaline solution and the recovery of the solution after the test;
2. The pumping motor of the high-performance plastic pump head can pump the alkaline solution from the stainless steel water tank into the test barrel according to the set time. At the same time, the plastic pump head will not rust and oxidize, and is durable;
3. The inner barrel of the test is made of SUS316# mirror stainless steel, which is beautiful and resistant to acid and alkali; the barrel is divided into inner and outer layers, the middle is polyurethane foam insulation, and the outer box is cold-rolled steel sprayed;
4. PLC + touch screen control, the system automatically completes the entire test, saving worry and trouble;
5. The power system is provided by a servo motor, which has the characteristics of large torque, large speed span, and stable operation;
6. The temperature control system adopts Siemens temperature module, PID automatic calculation, high control precision and stable operation;
7. Protection system: The entire test system is composed of two parts: the inner barrel and the outer box. It has strong explosion-proof performance. Even if the battery explodes in the test inner box, it will not cause damage to places outside the test box;
8. Drainage system: The equipment is equipped with an automatic drain valve at the bottom of the liquid collection tank to facilitate the discharge of test water to the outdoors;
9. Convenient design for adding water: The top of the water tank is designed with a large open cover. When water is needed, the entire tank cover can be removed, and it can be covered at ordinary times to prevent dust;
10. Humanized operation design: The operation of the entire test is completed within the range of one meter to one meter five. The operator can comfortably complete various operations without squatting or deliberately climbing;
11. Movable function design: 4 universal wheels and foot cups are installed at the bottom of the whole test box. The equipment can be easily moved to the place where it needs to be placed. The foot cups can fix the equipment in the required position.
Fulfill the standard
GB Safety requirements for lithium-ion batteries and battery packs for portable electronic products
