| I. Control methods and characteristics |
| Using low-temperature and high-temperature thermal storage tanks, the test needs to move the test product to achieve a rapid impact effect, balance the temperature control system (BTC), and control the SSPR by P.I.D., so that the heating capacity of the system is equal to the heat loss, so that it can be long-term use. |
| Ⅱ. Performance:(Air-cooled, refers to room temperature at +25℃, when no load) | |
| 1.High temperature tank impact range | +40℃ ～ +150℃ |
| 2.Low temperature tank impact range | -40℃ ～ -10℃ |
| 3.High temperature tank temperature range | +60℃ ～ +200℃ |
| 4.Low temperature tank temperature range | -65℃ ～ -10℃ |
| 5.Impact reset time | -40℃ ～ +150℃ Approximately 5min without load (the sensor is placed at the air outlet of the unit) |
| 6.Temperature uniformity | ±2.0℃ |
| 7.Temperature fluctuation | ±0.5℃ |
| 8.High and low temperature Impact constant temperature time |
≤30S |
| 9.Basket transfer time | ≦10 seconds (pneumatic automatic conversion) |
| The temperature performance test is measured according to the relevant provisions of the IEC60068-3 standard; the sensor is placed at the air outlet of the unit | |
