| Item | PW-UTM50K1 | PW-UTM50K2 |
| Capacity (MAX) | 50KN (optional 10N~50KN range force sensor) | |
| Control mode | full computer control mode, powerful software function | |
| Power unit | N, kN, gf, kgf, lbf, kP, tf (SI), tf (long), etc. | |
| Length unit | mm, cm, Inch, m, km, um, etc. | |
| Power resolution | 1/500,000; | |
| Accuracy | ±0.1% | |
| Travel resolution | 1/500,000mm | |
| Accuracy | ±0.1% | |
| Effective stroke | 700mm; (customizable) | 1200mm; (customizable) |
| Speed range | 0.01~500mm/min; (customizable) | |
| Test space | 420mm left and right (customizable) | |
| Shutdown mode | overload shutdown, emergency stop button, automatic shutdown of specimen damage, automatic shutdown of upper and lower limit settings | |
| Machine power | Servo motor drive | |
| Machine size (W×D×H) | 88×66×208cm | 108×66×208cm |
| Net weight of machine | 420KG | 480KG |
| Power | 400W | |
| Power supply | 220V 50~60HZ | |
| Machine equipment | 1 USB communication line, 1 software | |
| Optional accessories | tensile fixture, compression fixture, etc.; (purchase different fixtures according to different test standards) |
|
